Nút Nhấn Khẩn Địa Chỉ 55000-908APO

Mã sản phẩm: 55000-908APO

– Call Point Type: Deformable element

– Call Point Principle: Operation of a switch

– Alarm Indicator: Red Light Emitting Diode (LED)

– Fault Indicator: Amber/yellow light emitting diode (LED)

– Supply Wiring: Two-wire supply, polarity sensitive

– Loop connections L1/L2: Terminal block

– Điên áp hoạt động: 17V-28V dc

– Communication Protocol: 5V-9V peak to peak

– Quiescent Current: 100μA

– Power-up Surge Current: 1mA

– Maximum Power-up Time: 1 second

– Alarm Current, LED illuminated: 4mA

– Normal Analogue Value: 16

– Alarm State Value: 64

– Temperature Range:
+ Max. continuous operating: +60°C

+ Min. continuous operating: 0°C

+ Min. operating: -20°C (không ngưng tụ/đóng băng)

+ Lưu trữ: -30°C to +80°C

– Độ ẩm: (không ngưng tụ) 0 to 95% relative humidity

– Compliance Standard:
+ EN54-11:2001
+ EN54-17:2005 (isolated version)
– IP Rating: 24

– Dimensions:
+ 89mm x 93mm x 26.5mm (manual call point)
+ 87mm x 87mm x 32mm (back box)
– Trọng lượng: 151g

– Materials:

+ Housing: Red Polycarbonate/ ABS
+ Hinged cover and locking tag are also available, part number: 26729-152
